FingerPrint Scanner Sensor

9000 - Fingerprint Scanner

9000 – Fingerprint Scanner

Fingerprint sensorTechnical Details

  • Fingerprint scanning window size: 16 x 20 mm
  • Image size: 288 x 240 pixel
  • Image Resolution : 500 DPI
  • Sensor Scan Area : 14.6 x 12.2 mm
  • Image gray level : 8bit/pixel, max 256 gray level
  • Operating voltage : 5 V DC single supply by USB Port
  • Reader size : 70 x 35 x 12 mm
  • Operating temperature : 0 °C – 70° C
  • Operating humidity : 0% – 85 %
  • Operating system : Microsoft Window XP 200 and 2003
  • Application : Security for PC’s and networks, E-commerce,
  • Banking and financial system security

^ Go Top
click here to close

M301 Fingerpring Scanner

M301 Fingerpring Scanner

M301 - Fingerprint sensor

Technical Details

  • Resolution : upto 500 DPI
  • Registration Speed: < 0.5 sec
  • Communication Mode: USB
  • Fingerprint Sensor : Optical Sensor
  • Operating System : Window 2000 / XP / 2003 / Vista / 7 Linux 32 / 64 bit (Optional)
  • Operating Temperature : 0° C – 45° C
  • Operating Humidity : 10% – 95 %
  • Application : Security for PCs and networks, E-commerce, Banking and financial system security

^ Go Top
click here to close


ZK 7000 USB Optical Sensor

ZK 7000 USB Optical Sensor

7000 - Fingerprint sensorIntroduction

This USB fingerprint reader designed for use with enteprise software applications and developer tools.
The user simply places their fingerprint on the glowing reader window, and the reader quickly and automatically
scans the fingerprint. On-board electronics calibrate the reader and encrypt the scanned data before sending
it over the USB interface. High performancde fingerprint reader for precise authentication with PC or network security.

Technical Specification

  • Size:79 x 49 x 32 mm
  • Resolution : upto 500 DPI
  • Communication Mode : USB
  • Fingerprint Sensor : Optical Sensor
  • Operating System: Window 98, Me, NT 4.0, 2000, XP, Vista
  • Temperature : 0 °C-45° C
  • Operating Humidity: 20% – 80%
  • Application : Security for PCs and networks, E-commerce, Banking and financial system security

^ Go Top

click here to close

ZK 7500 USB Fingerprint Scanner

ZK 7500 USB Fingerprint Scanner

7500 - Fingerprint sensor

Features

High performance fingerprint reader for precise authentication for PC or network security.
Excellent adaptation for dry and wet fingerprint USB interface facilitates communication
Outstanding authentication performance combined with finger SDK

Technical Specification

  • Size:79 x 49 x 32 mm
  • Resolution : upto 500 DPI
  • Image Size: 15.4 x 18.0 mm
  • Interface: USB 1.1 / 2.0
  • Fingerprint Sensor : Optical Sensor
  • Operating System: Window 2000, XP,2003, Vista, 7 (32/64 bit) and Linux OS
  • OperatingTemperature : 0 °C-45° C
  • Operating Humidity: 20% – 80%
  • Application : Security for PCs and networks, E-commerce, Banking and financial system security
