Network Video Recorder – NVR

VS-12164U-RP Pro (Network Video Recorder)

VS-12164U-RP Pro (Network Video Recorder)

nvrComplete Recording Functions

High Quality H.264, MPEG-4, M-JPEG, and MxPEG Recording (depending on the camera models)





All-in-one Recording Functions

  • audirecordContinuous, manual, and scheduled recording *
  • Alarm recording (by multiple events), alarm recording schedule *
  • Pre-alarm and post-alarm recording
  • Audio recording* Different recording schedules for the IP cameras.

megapixelMegapixel Recording
The VioStor NVR supports megapixel recording (up to 10-megapixel) from various IP cameras.

ipcamerasGeneric IP Cameras Support
The VioStor NVR provides an interface for the users to enter the JPEG CGI command of their IP cameras to retrieve the video and audio data from the IP cameras.

watermarkReal-time Digital Watermarking
The VioStor NVR supports real-time digital watermarking to protect the videos and snapshots from unauthorized modification. The Watermark Proof utility is provided to verify whether or not the videos and snapshots are original.

vgaconnectorPC-less Network Surveillance by HD Local Display via VGA Connector





Diversified Modes for Local Monitoring

  • 1, 4, 6, 8, 9, 10, or 12-channel display mode
  • Sequential display mode

High Resolution Local Display

VioStor NVR supports widescreen VGA monitor or TV of different resolutions, up to full HD (1920 x 1080).

Convenient Control of PTZ and Speed Dome Cameras

The PTZ (Pan/Tilt/Zoom) cameras can be adjusted directly and the preset positions of the IP cameras can be viewed on the local display interface of the VioStor NVR.

Digital Zoom

Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces of the NVR.

On-screen Event Alert

When an event occurs, an alert icon will be shown instantly on local monitoring page. The alert details can be viewed by clicking the alert icon.

Video Search

The VioStor NVR supports convenient video search by date and time on the local playback interface.

vgamonitorLocal Video Playback on VGA Monitor or TV

The VioStor NVR supports video playback directly on a VGA monitor or TV.

Quick System Setup

The VioStor NVR can be set up in simple steps on the local display interface.

Network Surveillance by Web-based Interface (Internet Explorer)

Real-time Remote Monitoring

Multi-server Monitoring

Connect to one VioStor NVR and monitor up to 128 channels from other VioStor NVR servers over LAN or WAN by an IE browser.

Diversified Remote Monitoring Modes

  • 1, 4, 6, 8, 9, 10, 12, 16, 20, 25, 36, or 42-channel and sequential display mode
  • Exclusive Picture-in-Picture mode
  • Multi-display mode

ptzSmart Control of PTZ & Speed Dome Cameras

The PTZ (Pan/Tilt/Zoom) cameras can be adjusted directly by the web user interface of the VioStor NVR.



cameraPreset Position Control and Auto Cruising

The preset positions of an IP camera can be viewed by clicking the corresponding number buttons on the monitoring page. The time interval can also be configured on the PTZ cameras for periodic monitoring.



alarmInstant Event Notification

When alarm recording is enabled and an event occurs, an alarm icon is shown instantly on the monitoring page. The alert details can be viewed by clicking the icon.



zoomDigital Zoom

Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces.

dynamicmapDynamic E-map

The VioStor NVR provides an E-map function for users to upload the digital maps and indicate the locations of the IP cameras of a monitoring location or region.

Multiview1Remote Video Playback

Multi-view Playback

Use the multi-view playback feature to divide a video equally into multiple sessions for playback in a multi-view window, or play the videos of multiple IP cameras in the multi-view window simultaneously.

Video Search by Date and Time, Timeline, Event,Intelligent Video Analytics (IVA)

The VioStor NVR supports quick video search by date and time, timeline, event, and intelligent video analytics (IVA), which includes motion detection, foreign object, missing object, out of focus, and camera occlusion.

Event Management

eventsAdvanced Event Management

The VioStor NVR supports various event handling options for different kinds of events.

  • Events: Motion detection, alarm input, connection failure, recording failure, and user-defined event.
  • Actions: Video recording, email alert, SMS alert, buzzer, PTZ camera control, alarm output, and user-defined action.

Real-timesms SMS and Email Alert

Configure the SMTP server and SMSC server settings on the NVR in order to receive instant system warning or error messages by email and/or SMS.

Convenient Backup Solution

Scheduled Remote Replication

The VioStor NVR supports scheduled remote replication for secure data backup to a remote QNAP NAS on the local network.

authorirySecurity Control

Authority Management

The administrator can create multiple users on the VioStor NVR and assign them to different user groups (administrator, system manager, or user) with different rights of monitoring, playback, PTZ control, and audio monitoring.



logoffAuto Logoff

The VioStor NVR supports automatic user logoff from idling configuration pages. The administrator can set the timeout period to log off the users when the idling time has reached.



accesscontrolHost Access Control

Specify the host or IP connections to be allowed and denied to access the NVR.



userlistOn-line User List

View the record of users currently logged on and previously logged on to the NVR.



eventlogDetailed Event Logs

The VioStor NVR provides detailed event logs of system warning, hard disk error, network disconnection, UPS status, and access to the networking services of the NVR and video recordings.

High Reliability and Smart Features

Advanced RAID with Hot-swap Design

The VioStor NVR supports RAID 0, 1, 5, 6, 5+hot spare, 6+hot spare, single, and JBOD disk configurations. Its hot-swap design allows a failed drive of a disk volume, RAID 1 or above, to be replaced by hot swapping without turning off the NVR.

Online RAID Capacity Expansion and Online RAID Level Migration

  • onlineraid_expOnline RAID Capacity ExpansionThe storage capacity of a RAID configuration can be expanded by replacing the hard drives with larger ones. All the data will be kept and seamlessly moved to the newly installed hard drives. There is no need to turn off the NVR during the process.
  • onlineraid_migOnline RAID Level MigrationUpgrade the disk configuration to higher RAID level with the data retained without turning off the NVR.



hhsS.M.A.R.T. & Advanced HDD Health Scanning (HHS)

Self-Monitoring Analysis and Reporting Technology (S.M.A.R.T.) helps the administrator monitor the hard disk drives status. The VioStor NVR supports Hard Drive Health Scan (HHS) for disk checking and bad blocks scanning.



PowerRecoveryAutomatic System Startup after Power Recovery

The VioStor NVR supports automatic system startup after a power recovery.



upssupportUPS Support for 24/7 Service

The VioStor NVR supports APC, CyberPower, MGE, and YEC UPS devices to provide continuous services 24/7 against unexpected power outage.

DOM Architecture with Embedded Fail-safe Dual OS for Enhanced Reliability

All the OS and applications of the VioStor NVR are embedded on the DOM. The VioStor NVR allows system booting without accessing the physical disk sectors which prevents unsuccessful system startup caused by bad blocks or file errors on the hard drives. Two operating systems are built on the DOM for system booting alternatively upon every system startup. When one fails, the other one for system startup and the failed OS is recoverable from the other healthy OS.

Network Services

Four Gigabit LAN Ports

  • FailoverThe LAN ports of the VioStor NVR can be configured in failover mode which allows the NVR to sustain the failure of one network interface and provide continuous services.
  • Load BalancingThe LAN ports of the VioStor NVR can be configured in load balancing mode for bandwidth aggregation to boost file transfer speeds. It works with managed Ethernet switch with 802.3ad configured.
  • Multi-IP Settings Four IP settings can be configured on the NVR to allow network access from four different subnets.

Built-in DDNS Service

The VioStor NVR supports dynamic DNS (DDNS) for convenient access to the system via a domain name instead of a lengthy IP address.

Built-in NTP Server

This feature allows the connected IP cameras to synchronize their date and time settings with the NVR.

dataaccessConvenient Data Access

The video data on the VioStor NVR can be accessed by the following protocols with proper access rights:

  • SMB/CIFS (Windows)
  • HTTP (Web file management)
  • FTP

Easy Configuration and Management

System Setup in Simple Steps

The NVR can be set up in 6 simple steps by the local display or web-based interface (Internet Explorer).

Web-based User Interface

All system configurations, monitoring, and playback features of the NVR can be managed by the web-based interface.

Smart Search of IP Cameras for Quick Settings

QNAP provides an intelligent software utility Finder for quick IP cameras search and system settings on the local network.

Excellent Hardware Design

Intel® Xeon® E3 CPU and ECC DDRIII Memory for Superior System Performance

Powered by Intel® Xeon® E3 CPU and ECC DDRIII memory, the VioStor NVR delivers superior performance for surveillance applications.

Redundant Power Supply

The VS-12164U-RP Pro is equipped with two power supply units, each of which is capable of supplying the power for the entire VioStor NVR independently. If one of the units fails, the other one will take over to supply the power to ensure continuous operation of the VioStor NVR. The failed power supply unit can be replaced without turning off the NVR.

Linux Embedded System

The Linux-based VioStor NVR is more power-saving and less vulnerable to virus attack compared to PC-based surveillance solution.

Huge Storage Capacity for Long-term Recording

The VioStor NVR supports up to 48TB of physical storage capacity (4TB hard drive x 12) for recording large amount of video data in a long period of time.

^ Go Top

click here to close



VS-8148U-RP Pro (Network Video Recorder)

VS-8148U-RP Pro (Network Video Recorder)

VS8148U-RP_01Complete Recording Functions

High Quality H.264, MPEG-4, M-JPEG, and MxPEG Recording (depending on the camera models)

audirecordAll-in-one Recording Functions

  • Continuous, manual, and scheduled recording *
  • Alarm recording (by multiple events), alarm recording schedule *
  • Pre-alarm and post-alarm recording
  • Audio recording* Different recording schedules for the IP cameras.

megapixelMegapixel Recording

The VioStor NVR supports megapixel recording (up to 10-megapixel) from various IP cameras.

ipcamerasGeneric IP Cameras Support

The VioStor NVR provides an interface for the users to enter the JPEG CGI command of their IP cameras to retrieve the video and audio data from the IP cameras.



watermarkReal-time Digital Watermarking

The VioStor NVR supports real-time digital watermarking to protect the videos and snapshots from unauthorized modification. The Watermark Proof utility is provided to verify whether or not the videos and snapshots are original.

PC-less Network Surveillance by HD Local Display via VGA Connector

Diversified Modes for Local Monitoring

  • 1, 4, 6, 8, 9, 10, or 12-channel display mode
  • Sequential display mode

High Resolution Local Display

VioStor NVR supports widescreen VGA monitor or TV of different resolutions, up to full HD (1920 x 1080).

Convenient Control of PTZ and Speed Dome Cameras

The PTZ (Pan/Tilt/Zoom) cameras can be adjusted directly and the preset positions of the IP cameras can be viewed on the local display interface of the VioStor NVR.

Digital Zoom

Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces of the NVR.

On-screen Event Alert

When an event occurs, an alert icon will be shown instantly on local monitoring page. The alert details can be viewed by clicking the alert icon.

Video Search

The VioStor NVR supports convenient video search by date and time on the local playback interface.

vgamonitorLocal Video Playback on VGA Monitor or TV

The VioStor NVR supports video playback directly on a VGA monitor or TV.

Quick System Setup

The VioStor NVR can be set up in simple steps on the local display interface.

Network Surveillance by Web-based Interface (Internet Explorer)

Real-time Remote Monitoring

Multi-server Monitoring

Connect to one VioStor NVR and monitor up to 128 channels from other VioStor NVR servers over LAN or WAN by an IE browser.

Diversified Remote Monitoring Modes

  • 1, 4, 6, 8, 9, 10, 12, 16, 20, 25, 36, or 42-channel and sequential display mode
  • Exclusive Picture-in-Picture mode
  • Multi-display mode

ptzSmart Control of PTZ & Speed Dome Cameras

The PTZ (Pan/Tilt/Zoom) cameras can be adjusted directly by the web user interface of the VioStor NVR.



cameraPreset Position Control and Auto Cruising

The preset positions of an IP camera can be viewed by clicking the corresponding number buttons on the monitoring page. The time interval can also be configured on the PTZ cameras for periodic monitoring.



alarmInstant Event Notification

When alarm recording is enabled and an event occurs, an alarm icon is shown instantly on the monitoring page. The alert details can be viewed by clicking the icon.



zoomDigital Zoom

Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces.

dynamicmapDynamic E-map

The VioStor NVR provides an E-map function for users to upload the digital maps and indicate the locations of the IP cameras of a monitoring location or region.

Multiview1Remote Video Playback

Multi-view Playback

Use the multi-view playback feature to divide a video equally into multiple sessions for playback in a multi-view window, or play the videos of multiple IP cameras in the multi-view window simultaneously.

Video Search by Date and Time, Timeline, Event,Intelligent Video Analytics (IVA)

The VioStor NVR supports quick video search by date and time, timeline, event, and intelligent video analytics (IVA), which includes motion detection, foreign object, missing object, out of focus, and camera occlusion.

Event Management

Advanced Event Management

eventsThe VioStor NVR supports various event handling options for different kinds of events.

  • Events: Motion detection, alarm input, connection failure, recording failure, and user-defined event.
  • Actions: Video recording, email alert, SMS alert, buzzer, PTZ camera control, alarm output, and user-defined action.

smsReal-time SMS and Email Alert

Configure the SMTP server and SMSC server settings on the NVR in order to receive instant system warning or error messages by email and/or SMS.

Convenient Backup Solution

Scheduled Remote Replication

The VioStor NVR supports scheduled remote replication for secure data backup to a remote QNAP NAS on the local network.

Security Control

authoriryAuthority Management

The administrator can create multiple users on the VioStor NVR and assign them to different user groups (administrator, system manager, or user) with different rights of monitoring, playback, PTZ control, and audio monitoring.



logoffAuto Logoff

The VioStor NVR supports automatic user logoff from idling configuration pages. The administrator can set the timeout period to log off the users when the idling time has reached.



accesscontrolHost Access Control

Specify the host or IP connections to be allowed and denied to access the NVR.



userlistOn-line User List

View the record of users currently logged on and previously logged on to the NVR.



eventlogDetailed Event Logs

The VioStor NVR provides detailed event logs of system warning, hard disk error, network disconnection, UPS status, and access to the networking services of the NVR and video recordings.

High Reliability and Smart Features

Advanced RAID with Hot-swap Design

The VioStor NVR supports RAID 0, 1, 5, 6, 5+hot spare, 6+hot spare, single, and JBOD disk configurations. Its hot-swap design allows a failed drive of a disk volume, RAID 1 or above, to be replaced by hot swapping without turning off the NVR.

Online RAID Capacity Expansion and Online RAID Level Migration

  • onlineraid_expOnline RAID Capacity ExpansionThe storage capacity of a RAID configuration can be expanded by replacing the hard drives with larger ones. All the data will be kept and seamlessly moved to the newly installed hard drives. There is no need to turn off the NVR during the process.
  • onlineraid_migOnline RAID Level MigrationUpgrade the disk configuration to higher RAID level with the data retained without turning off the NVR.



hhsS.M.A.R.T. & Advanced HDD Health Scanning (HHS)

Self-Monitoring Analysis and Reporting Technology (S.M.A.R.T.) helps the administrator monitor the hard disk drives status. The VioStor NVR supports Hard Drive Health Scan (HHS) for disk checking and bad blocks scanning.



PowerRecoveryAutomatic System Startup after Power Recovery

The VioStor NVR supports automatic system startup after a power recovery.



upssupportUPS Support for 24/7 Service

The VioStor NVR supports APC, CyberPower, MGE, and YEC UPS devices to provide continuous services 24/7 against unexpected power outage.

DOM Architecture with Embedded Fail-safe Dual OS for Enhanced Reliability

All the OS and applications of the VioStor NVR are embedded on the DOM. The VioStor NVR allows system booting without accessing the physical disk sectors which prevents unsuccessful system startup caused by bad blocks or file errors on the hard drives. Two operating systems are built on the DOM for system booting alternatively upon every system startup. When one fails, the other one for system startup and the failed OS is recoverable from the other healthy OS.

Network Services

Dual Gigabit LAN Ports

  • FailoverThe LAN ports of the VioStor NVR can be configured in failover mode which allows the NVR to sustain the failure of one network interface and provide continuous services.
  • Load BalancingThe LAN ports of the VioStor NVR can be configured in load balancing mode for bandwidth aggregation to boost file transfer speeds. It works with managed Ethernet switch with 802.3ad configured.
  • Multi-IP Settings Two IP settings can be configured on the NVR to allow network access from two different subnets.

Built-in DDNS Service

The VioStor NVR supports dynamic DNS (DDNS) for convenient access to the system via a domain name instead of a lengthy IP address.

Built-in NTP Server

This feature allows the connected IP cameras to synchronize their date and time settings with the NVR.

dataaccessConvenient Data Access

The video data on the VioStor NVR can be accessed by the following protocols with proper access rights:

  • SMB/CIFS (Windows)
  • HTTP (Web file management)
  • FTP

Easy Configuration and Management
System Setup in Simple Steps

The NVR can be set up in 6 simple steps by the local display or web-based interface (Internet Explorer).

Web-based User Interface

All system configurations, monitoring, and playback features of the NVR can be managed by the web-based interface.

Smart Search of IP Cameras for Quick Settings

QNAP provides an intelligent software utility Finder for quick IP cameras search and system settings on the local network.

Excellent Hardware Design
Intel® Core™ i3 CPU and DDRIII Memory for Superior System Performance

Powered by Intel® Core™ i3 CPU and DDRIII memory, the VioStor NVR delivers superior performance for surveillance applications.

Redundant Power Supply

The VS-8148U-RP Pro is equipped with two power supply units, each of which is capable of supplying the power for the entire VioStor NVR independently. If one of the units fails, the other one will take over to supply the power to ensure continuous operation of the VioStor NVR. The failed power supply unit can be replaced without turning off the NVR.

NVR.Linux Embedded System

The Linux-based VioStor NVR is more power-saving and less vulnerable to virus attack compared to PC-based surveillance solution.

Touch-N-Go PC-less Installation

Complete the first-time system installation, including hard disk initialization and RAID configuration, of the NVR by the LCD panel without using any PC.

Huge Storage Capacity for Long-term Recording

The VioStor NVR supports up to 24TB of physical storage capacity (3TB hard drive x 8) for recording large amount of video data in a long period of time.

^ Go Top

click here to close



VS-6120 Pro+ (Network Video Recorder)

VS-8148U-RP Pro (Network Video Recorder)

Surveillance Features

mxpeg01Complete Recording Functions

High Quality H.264, MPEG-4, M-JPEG and MxPEG Recordings (depending on the camera models)





audirecordAll-in-one Recording Functions

  • Continuous/manual/scheduled recording *
  • Alarm recording (by multiple events), alarm recording schedule *
  • Pre-alarm and post-alarm recording
  • Audio recording
  • Auto snapshots* Different recording schedules for the IP cameras.

megapixelMegapixel Recordings

The VioStor NVR supports megapixel recordings (up to 10-megapixel) from various IP cameras.

watermarkReal-time Digital Watermarking

The VioStor NVR supports real-time digital watermarking to protect the videos and snapshots from unauthorized modifications. The Watermark Proof utility is provided to verify whether or not the videos and snapshots are original.

Network Surveillance with Full HD 1080P Local Display

Multiview1Diversified Modes for Local Monitoring

  • 1, 4, 6, 8, 9, 10, 12, or 16-channel display modes
  • Sequential display mode

High Resolution Local Display

The VioStor NVR provides an HDMI port which can be connected to an HDMI monitor or TV for doing monitoring in the full HD (1920 x 1080) resolution.

Convenient Control of PTZ and Speed Dome Cameras

The PTZ (Pan/Tilt/Zoom) cameras can be adjusted directly and the preset positions of the IP cameras can be viewed on the local display interface of the VioStor NVR.

Digital Zoom

Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces of the NVR.

On-screen Event Alert

When an event occurs, an alert icon will be shown instantly on the local monitoring page. The alert details can be viewed by clicking the alert icon

VideoSearch01Video Search

The VioStor NVR supports convenient video search by date and time on the local playback interface.

Local Video Playbacks on HDMI Monitors or TVs

The VioStor NVR supports direct video playbacks on HDMI monitors or TVs.

QuickSystemSetup01Quick System Setup

The VioStor NVR can be set up in simple steps on the local display interface.

Network Surveillance by Web-based Interface to Perform

Real-time Remote Monitoring

Cross-platform Support

Use QNAP Surveillance Client for Windows and Mac to watch the live view and play back the recording files on the VioStor NVR.

Cross-browser Compatibility

On the Windows PC, you can also use Google Chrome, Microsoft Internet Explorer, or Mozilla Firefox to enjoy our surveillance features.

MultiserverMonitoring01Multi-server Monitoring

Connect to one VioStor NVR and monitor up to 128 channels from other VioStor NVR servers over the LAN or WAN via an IE browser.

Note: The feature is supported by Google Chrome, Microsoft Internet Explorer, and Mozilla Firefox.

RemoteMonitoringModes01Diversified Remote Monitoring Modes

  • 1, 4, 6, 8, 9, 10, 12, 16, 20, 25, 36, 42, 64-channel, and sequential display modes
  • Dual-display mode

ptzSmart Control of PTZ & Speed Dome Cameras

The PTZ (Pan/Tilt/Zoom) cameras can be directly adjusted by the web user interface of the VioStor NVR.

cameraPreset Position Control and Auto Cruising

The preset positions of an IP camera can be viewed by clicking the corresponding number buttons on the monitoring page. The time interval can also be configured on the PTZ cameras to perform periodic monitoring.

alarmInstant Event Notification

When the alarm recording is enabled and an event occurs, an alarm icon will be shown instantly on the monitoring page. The alert details can be viewed by clicking the icon.

zoomDigital Zoom

Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces.

dynamicmapDynamic E-map

The VioStor NVR provides the E-map function for users to upload the digital maps and indicate the locations of the IP cameras of a monitoring location or region.

MultiviewPlayback01Remote Video Playback

Multi-view Playback

Use the multi-view playback feature to divide a video equally into multiple sessions for doing playback in a multi-view window, or play the videos of multiple IP cameras in the multi-view window simultaneously.

Video Search by Date and Time, Timeline, Event,Intelligent Video Analytics (IVA)

The VioStor NVR supports quick video search by date and time, timeline, event, and intelligent video analytics (IVA), which includes motion detection, foreign object, missing object, out of focus, and camera occlusion.

Event Management

eventsAdvanced Event Management

VioStor NVR supports various event handling options for different kinds of events.

  • Events: Motion detection, alarm input, connection failure, recording failure, and user-defined event.
  • Actions: Video recording, email alert, SMS alert, buzzer, PTZ camera control, alarm output, and user-defined action.

smsReal-time SMS and Email Alert

Configure the SMTP server and SMSC server settings on the NVR in order to receive instant system warnings or error messages by email and/or SMS

Convenient Backup Solution

Scheduled Remote Replication

The VioStor NVR supports scheduled remote replication for performing secure data backup to a remote QNAP NAS on the local network.

One Touch Auto Video Backup

Configure the one touch auto video backup button at the front of the NVR to copy the data from the NVR to an external storage device when the button is pressed.

Excellent Hardware Design

Intel® CPU and DDRIII Memory for Superior System Performance

Powered by the Intel® CPU and DDRIII memory, the VioStor NVR delivers superior performance for surveillance applications.

CPU Thermal Solution with Fan-Less Design

Fan-less design provides better performance, quiet operation, lower energy costs, and enhanced reliability.

Built-in Japanese Sanyodenki System Fan

  • Twice the lifespan of the competitors (at 85℃)
  • Lower failure rate (100% inspection in the Sanyodenki production line)

Linux Embedded System

The Linux-based VioStor NVR is more power-saving and less vulnerable to virus attacks compared to the PC-based surveillance solution.

Touch-N-Go PC-less Installation

Complete the first-time system installation, including hard disk initialization and RAID configuration, of the NVR by the LCD panel without using any PC.

Huge Storage Capacity for Long-term Recordings

The VioStor NVR supports up to 16TB of physical storage capacity (4TB hard drive x 4) for recording a large amount of video data over a long period of time.

VMobilenetworksurveillance01Mobile Surveillance by VMobile

Use the VMobile network surveillance application on Android phone, Android Tablet, iPhone, iPad, or iPod touch to easily access video management functions Multi-view Playback

Use the multi-view playback featuresuch as remote live view and playback recordings. In addition, the account on the VioStor NVR can be used to connect to an unlimited number of NVRs and IP cameras by VMobile through Wi-Fi, 3G, or 4G networks.

Camera function

Fisheye Dewarping

The fisheye dewarping function, available on the web and local display interface for specific fisheye cameras and specific cameras with panomorph lens, assists in doing practical surveillance management, allowing the administrators to view the monitoring area in a clearer shape.

Security Control

authoriryAuthority Management

Create multiple users on the VioStor NVR and assign them to different user groups (administrator, system manager, or user) with different rights for doing monitoring, playback, PTZ control, and audio monitoring.

logoffAuto Logoff

The VioStor NVR supports automatic user logoff from idling configuration pages. The administrator can set the timeout period to log off the users when the idling time has been reached.

accesscontrolHost Access Control

Specify the host or IP connections to be allowed or denied to access the NVR.

userlistOn-line User List

View the record of users currently logged on and previously logged on to the NVR.

eventlogDetailed Event Logs

The VioStor NVR provides detailed event logs of system warnings, hard disk errors, network disconnections, UPS status, and access to the networking services of the NVR and video recordings

High Reliability and Smart Features

Advanced RAID with Hot-swap Design

The VioStor NVR supports RAID 0, 1, 5, 6, 5+hot spare, single, and JBOD disk configurations. Its hot-swap design allows a failed drive of a disk volume (RAID 1 or above) to be replaced by hot swapping without turning off the server.

Online RAID Capacity Expansion and Online RAID Level Migration

  • onlineraid_expOnline RAID Capacity ExpansionThe storage capacity of a RAID configuration can be expanded by replacing the hard drives with larger ones. All the data will be kept and seamlessly moved to the newly installed hard drives. There is no need to turn off the server during the process.
  • onlineraid_migOnline RAID Level MigrationUpgrade the disk configuration to a higher RAID level with the data retained without turning off the server.



S.M.A.R.T. & Advanced HDD Health Scanning (HHS)

hhsS.M.A.R.T. (Self-Monitoring Analysis and Reporting Technology) helps monitor the hard disk drives status. The VioStor NVR supports HHS (HDD Health Scan) for doing disk checking and bad blocks scanning.

PowerRecoveryAutomatic System Startup after Power Recovery

The VioStor NVR supports automatic system startup after a power recovery.

upssupportUPS Support for 24/7 Service

The VioStor NVR supports APC, CyberPower, MGE, and YEC UPS devices to provide continuous services 24/7 against unexpected power outages.

DOM Architecture with Embedded Fail-safe Dual OS for Enhanced Reliability

All the OS and applications of the VioStor NVR are embedded in the DOM. The VioStor NVR allows system booting without accessing the physical disk sectors to prevent from unsuccessful system startup caused by bad blocks or file errors on the hard drives. Two operating systems are built on the DOM to boot the system alternatively upon every system startup. When one fails, the other one can be used for system startup and the failed OS is recoverable from the other healthy OS.

Network Services

dualgigaDual Gigabit LAN Ports

  • FailoverThis mode allows the VioStor NVR to sustain the failure of one network port to provide continuous services.
  • Load BalancingThis mode provides bandwidth aggregation to boost the file transfer speed (works with managed Ethernet switch with 802.3ad configured).
  • Multi-IP Settings Two IP settings can be configured on the NVR to allow network access from two different subnets.

Built-in DDNS Service

The VioStor NVR supports dynamic DNS (DDNS) for convenient access to the system by a domain name instead of a lengthy IP address.

Built-in NTP Server

This feature allows the connected IP cameras to synchronize their date and time settings with the NVR.

dataaccessConvenient Data Access

The video data on the VioStor NVR can be accessed via the following protocols with proper access rights:

  • SMB/CIFS (Windows).
  • HTTP (Web file management)
  • FTP

Easy Configuration and Management

System Setup in Simple Steps

The NVR can be set up in 6 simple steps via the local display or web-based interface (Internet Explorer).

Web-based User Interface

All the system configurations, monitoring, and playback features of the NVR can be managed by the web-based interface.

Smart Search of IP Cameras for Quick Settings

QNAP provides an intelligent software utility, Finder, to search for IP cameras and configure the system settings on the local network quickly.

^ Go Top

click here to close



VS-4116 Pro+ (Network Video Recorder)

VS-4116 Pro+ (Network Video Recorder)

Surveillance Features

Complete Recording Functions

mxpeg01High Quality H.264, MPEG-4, M-JPEG and MxPEG Recordings (depending on the camera models)





audirecordAll-in-one Recording Functions

  • Continuous/manual/scheduled recording *
  • Alarm recording (by multiple events), alarm recording schedule *
  • Pre-alarm and post-alarm recording
  • Audio recording
  • Auto snapshots* Different recording schedules for the IP cameras.

megapixelMegapixel Recordings

The VioStor NVR supports megapixel recordings (up to 10-megapixel) from various IP cameras.

watermarkReal-time Digital Watermarking

The VioStor NVR supports real-time digital watermarking to protect the videos and snapshots from unauthorized modifications. The Watermark Proof utility is provided to verify whether or not the videos and snapshots are original.

Network Surveillance with Full HD 1080P Local Display

Multiview1Diversified Modes for Local Monitoring

  • 1, 4, 6, 8, 9, 10, 12, or 16-channel display modes
  • Sequential display mode

High Resolution Local Display

The VioStor NVR provides an HDMI port which can be connected to an HDMI monitor or TV for doing monitoring in the full HD (1920 x 1080) resolution.

Convenient Control of PTZ and Speed Dome Cameras

The PTZ (Pan/Tilt/Zoom) cameras can be adjusted directly and the preset positions of the IP cameras can be viewed on the local display interface of the VioStor NVR.

Digital Zoom

Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces of the NVR.

On-screen Event Alert

When an event occurs, an alert icon will be shown instantly on the local monitoring page. The alert details can be viewed by clicking the alert icon

VideoSearch01Video Search

The VioStor NVR supports convenient video search by date and time on the local playback interface.

Local Video Playbacks on HDMI Monitors or TVs

The VioStor NVR supports direct video playbacks on HDMI monitors or TVs.

QuickSystemSetup01Quick System Setup

The VioStor NVR can be set up in simple steps on the local display interface.

Network Surveillance by Web-based Interface to Perform

Real-time Remote Monitoring

Cross-platform Support

Use QNAP Surveillance Client for Windows and Mac to watch the live view and play back the recording files on the VioStor NVR.

Cross-browser Compatibility

On the Windows PC, you can also use Google Chrome, Microsoft Internet Explorer, or Mozilla Firefox to enjoy our surveillance features.

MultiserverMonitoring01Multi-server Monitoring

Connect to one VioStor NVR and monitor up to 128 channels from other VioStor NVR servers over the LAN or WAN via an IE browser.

Note: The feature is supported by Google Chrome, Microsoft Internet Explorer, and Mozilla Firefox.

RemoteMonitoringModes01Diversified Remote Monitoring Modes

  • 1, 4, 6, 8, 9, 10, 12, 16, 20, 25, 36, 42, 64-channel, and sequential display modes
  • Dual-display mode

ptzSmart Control of PTZ & Speed Dome Cameras

The PTZ (Pan/Tilt/Zoom) cameras can be directly adjusted by the web user interface of the VioStor NVR.

cameraPreset Position Control and Auto Cruising

The preset positions of an IP camera can be viewed by clicking the corresponding number buttons on the monitoring page. The time interval can also be configured on the PTZ cameras to perform periodic monitoring.

alarmInstant Event Notification

When the alarm recording is enabled and an event occurs, an alarm icon will be shown instantly on the monitoring page. The alert details can be viewed by clicking the icon.

zoomDigital Zoom

Digital zoom (in/out) of the video image is supported on the monitoring and playback interfaces.

dynamicmapDynamic E-map

The VioStor NVR provides the E-map function for users to upload the digital maps and indicate the locations of the IP cameras of a monitoring location or region.

MultiviewPlayback01Remote Video Playback

Multi-view Playback

Use the multi-view playback feature to divide a video equally into multiple sessions for doing playback in a multi-view window, or play the videos of multiple IP cameras in the multi-view window simultaneously.

Video Search by Date and Time, Timeline, Event, Intelligent Video Analytics (IVA)

The VioStor NVR supports quick video search by date and time, timeline, event, and intelligent video analytics (IVA), which includes motion detection, foreign object, missing object, out of focus, and camera occlusion.

Event Management

eventsAdvanced Event Management

VioStor NVR supports various event handling options for different kinds of events.

  • Events: Motion detection, alarm input, connection failure, recording failure, and user-defined event.
  • Actions: Video recording, email alert, SMS alert, buzzer, PTZ camera control, alarm output, and user-defined action.

Real-time SMS and Email Alert

Configure the SMTP server and SMSC server settings on the NVR in order to receive instant system warnings or error messages by email and/or SMS

Convenient Backup Solutionsms

Scheduled Remote Replication

The VioStor NVR supports scheduled remote replication for performing secure data backup to a remote QNAP NAS on the local network.

One Touch Auto Video Backup

Configure the one touch auto video backup button at the front of the NVR to copy the data from the NVR to an external storage device when the button is pressed.

Excellent Hardware Design

Intel® CPU and DDRIII Memory for Superior System Performance

Powered by the Intel® CPU and DDRIII memory, the VioStor NVR delivers superior performance for surveillance applications.

CPU Thermal Solution with Fan-Less Design

Fan-less design provides better performance, quiet operation, lower energy costs, and enhanced reliability.

Built-in Japanese Sanyodenki System Fan

  • Twice the lifespan of the competitors (at 85℃)
  • Lower failure rate (100% inspection in the Sanyodenki production line)

Linux Embedded System

The Linux-based VioStor NVR is more power-saving and less vulnerable to virus attacks compared to the PC-based surveillance solution.

Touch-N-Go PC-less Installation

Complete the first-time system installation, including hard disk initialization and RAID configuration, of the NVR by the LCD panel without using any PC.

Huge Storage Capacity for Long-term Recordings

The VioStor NVR supports up to 16TB of physical storage capacity (4TB hard drive x 4) for recording a large amount of video data over a long period of time.

VMobilenetworksurveillance01Mobile Surveillance by VMobile

Use the VMobile network surveillance application on Android phone, Android Tablet, iPhone, iPad, or iPod touch to easily access video management functions Multi-view Playback

Use the multi-view playback featuresuch as remote live view and playback recordings. In addition, the account on the VioStor NVR can be used to connect to an unlimited number of NVRs and IP cameras by VMobile through Wi-Fi, 3G, or 4G networks.

Camera function

Fisheye Dewarping

The fisheye dewarping function, available on the web and local display interface for specific fisheye cameras and specific cameras with panomorph lens, assists in doing practical surveillance management, allowing the administrators to view the monitoring area in a clearer shape.

Security Control

authoriryAuthority Management

Create multiple users on the VioStor NVR and assign them to different user groups (administrator, system manager, or user) with different rights for doing monitoring, playback, PTZ control, and audio monitoring.

logoffAuto Logoff

The VioStor NVR supports automatic user logoff from idling configuration pages. The administrator can set the timeout period to log off the users when the idling time has been reached.

accesscontrolHost Access Control

Specify the host or IP connections to be allowed or denied to access the NVR.

userlistOn-line User List

View the record of users currently logged on and previously logged on to the NVR.

eventlogDetailed Event Logs

The VioStor NVR provides detailed event logs of system warnings, hard disk errors, network disconnections, UPS status, and access to the networking services of the NVR and video recordings

High Reliability and Smart Features

Advanced RAID with Hot-swap Design

The VioStor NVR supports RAID 0, 1, 5, 6, 5+hot spare, single, and JBOD disk configurations. Its hot-swap design allows a failed drive of a disk volume (RAID 1 or above) to be replaced by hot swapping without turning off the server.

Online RAID Capacity Expansion and Online RAID Level Migration

  • onlineraid_expOnline RAID Capacity ExpansionThe storage capacity of a RAID configuration can be expanded by replacing the hard drives with larger ones. All the data will be kept and seamlessly moved to the newly installed hard drives. There is no need to turn off the server during the process.
  • onlineraid_migOnline RAID Level MigrationUpgrade the disk configuration to a higher RAID level with the data retained without turning off the server.



hhsS.M.A.R.T. & Advanced HDD Health Scanning (HHS)

S.M.A.R.T. (Self-Monitoring Analysis and Reporting Technology) helps monitor the hard disk drives status. The VioStor NVR supports HHS (HDD Health Scan) for doing disk checking and bad blocks scanning.

PowerRecoveryAutomatic System Startup after Power Recovery

The VioStor NVR supports automatic system startup after a power recovery.

upssupportUPS Support for 24/7 Service

The VioStor NVR supports APC, CyberPower, MGE, and YEC UPS devices to provide continuous services 24/7 against unexpected power outages.

DOM Architecture with Embedded Fail-safe Dual OS for Enhanced Reliability

All the OS and applications of the VioStor NVR are embedded in the DOM. The VioStor NVR allows system booting without accessing the physical disk sectors to prevent from unsuccessful system startup caused by bad blocks or file errors on the hard drives. Two operating systems are built on the DOM to boot the system alternatively upon every system startup. When one fails, the other one can be used for system startup and the failed OS is recoverable from the other healthy OS.

Network Services

dualgigaDual Gigabit LAN Ports

  • FailoverThis mode allows the VioStor NVR to sustain the failure of one network port to provide continuous services.
  • Load BalancingThis mode provides bandwidth aggregation to boost the file transfer speed (works with managed Ethernet switch with 802.3ad configured).
  • Multi-IP Settings Two IP settings can be configured on the NVR to allow network access from two different subnets.

Built-in DDNS Service

The VioStor NVR supports dynamic DNS (DDNS) for convenient access to the system by a domain name instead of a lengthy IP address.

Built-in NTP Server

This feature allows the connected IP cameras to synchronize their date and time settings with the NVR.

dataaccessConvenient Data Access

The video data on the VioStor NVR can be accessed via the following protocols with proper access rights:

  • SMB/CIFS (Windows).
  • HTTP (Web file management)
  • FTP

Easy Configuration and Management

System Setup in Simple Steps

The NVR can be set up in 6 simple steps via the local display or web-based interface (Internet Explorer).

Web-based User Interface

All the system configurations, monitoring, and playback features of the NVR can be managed by the web-based interface.

Smart Search of IP Cameras for Quick Settings

QNAP provides an intelligent software utility, Finder, to search for IP cameras and configure the system settings on the local network quickly.

^ Go Top

click here to close

DHI-NVR5424-24P-4KS2_img
DHI-NVR5424-24P-4KS2_24channel_img
DHI-NVR4816_4832-16P_img
DHI-NVR4808_4816_4832_img
NVR4816_4832-16P-4KS2_img
NVR4408-4416-4432-8P_img
DHI-NVR4416_4432-16P_lite_nvr
NVR4416-4432-4KS2_4hdd_img
NVR4208-4216-4232-4KS2_img
NVR2208-8P-S2_img
NVR2204-P-S2_img
NVR4104-4108-4116HS-4KS2_img
NVR2108HS-8P-S2_img
NVR4104-4108-4116H_img
NVR4104-4108-4116H-P-img
NVR4108-4116H-8P-img
